Features

• IP alarm reporting and uploading/downloading capability for Internet and Intranet use via iGSMV4G, 7845i-ENT, GSMV4G or GSMX4G
• Six on-board hardwired zones
  – 16 hardwired expansion zones totalling 22
  – 26 wireless expansion zones
• Supports two graphic touchscreen keypads
• Eight independent keyfob zones allow wireless keys to be programmed without using any of the 26 zones
• Eight output devices
  – Relays (Model 4204 Relay Modules, or 4229 Expansion Module)
• Two low current on-board trigger outputs
• 50 Event Log viewable at system keypads with time/date stamp
• 32 system user codes
• Two installer configurable zone types allows the installer to “create custom zone types” by assigning all zone attributes
• Multiple actions on output devices depending on system “state”
  – Turns light off when system arms
  – Turns same lights on when system disarms
  – Flashes same lights when system is in alarm
• Built-in phone line cut monitor with programmable delay and annunciation options
  – Display on system keypads
  – Trigger local sounders
  – Trigger system bell
• Supports four-wire and up to 16 two-wire smokes
  – Works with Sentrol CleanMe™ maintenance signal

Valuable End-User Features

• Now viewable on system keypads:
  – Exit countdown
  – Time and date display*
  – Event log*
• Auto keypad backlighting on entry
• Keyswitch arming
• Programmable macro buttons and single-button arming
• A variety of wireless remote controls for single-button operation
• User Scheduling
  – Latchkey reports to pagers
  – Auto arm/disarm
  – “User access” time windows
• Supports up to two numeric pagers
• VIP Module allows system control from any touchtone phone
• Chime by zone
